Princess F55

motoryacht
Flybridge

Overview

Draft

Air draft

18 ft

Gallery

01 / 02

F Class2017 launch with 2022 exterior and interior updatecurrent

Dimensions

Published measurements and ranges

Hull length

Displacement

Capacities

Fresh water

Holding

Layout options

Select a published arrangement

Guest cabins

Heads

Crew cabins

Crew berths

Engine options

Published packages and performance data

Powerplant

2× Volvo Penta D13-800 800 hp

HP each

800 hp

diesel

Propulsion

shafts

Performance

Speed ranges and documented profiles

Top speed

Range

Speed

7.4 kn

Range

1,850 nm

2.9 gph

650 rpm

80% fuel; three people

Dimension variants

2017 Launch

LOA 57 ft 9 in · Beam 16 ft · Draft 4 ft 10 in

Brochure Generation

LOA 58 ft · Beam 16 ft · Draft 4 ft 7 in

Fort Lauderdale fit

Air draft 18 ft. 17th Street closed ≈ 55 ft. SE 3rd Avenue ≈ 16 ft. Manufacturer numbers, not a survey.

Survey watch points

Manufacturer publications disagree on key dimensions

medium risk · unresolved · dimensions

2017 launch release and current F55 brochure publish different LOA, hull length, full-load draft, fresh-water, and displacement figures. Root keeps launch lightship displacement only; do not span pubs as a min/max range.

Princess F55 manufacturer materials opened for research do not settle on one LOA, hull length, full-load draft, fresh-water, or displacement figure.

The 2017 launch release (princess-55-launch-release) lists 57 ft 9 in / 17.6 m LOA (incl. pulpit), 56 ft 7 in excl. pulpit, 4 ft 10 in / 1.46 m full-load draft, 161 USG water including calorifier, and 24.6 tonnes / 54,234 lb displacement approx (lightship). The current F55 brochure (princess-f55-current-model-page) lists 58 ft 0 in / 17.68 m LOA, 55 ft 8 in excl. pulpit, 4 ft 7 in / 1.41 m full-load draft, 164 US gal water excluding calorifier, and 30,924 kg / 68,176 lb displacement approx with an asterisk and no exposed load-basis footnote.

Canonical research keeps launch lightship on root displacement_lb_min / displacement_lb_max (same value; not a cross-publication span), records LOA/draft in dimension_variants, and leaves these paths in conflicting_fields instead of inventing midpoints or a fake light→loaded range. For Fort Lauderdale fit or tankage planning, verify the hull's build paperwork.

Confirm which published dimension set matches the surveyed hull build year and brochure revision.
Do not average LOA, hull length, draft, fresh-water capacity, or displacement across manufacturer publications.
Do not treat launch lightship and brochure displacement as a single light-to-loaded range.
Confirm whether fresh-water figures include or exclude the calorifier before comparing tankage.
Confirm displacement load basis on the hull's build paperwork before comparing weights.

Sources: princess-55-launch-release, princess-f55-current-model-page

Can a Princess F55 clear Fort Lauderdale bridges?

Published air draft is 18 ft hardtop. 17th Street closed is about 55 ft. SE 3rd Avenue is about 16 ft. Manufacturer numbers, not a listing photo.

What draft does a Princess F55 need in Fort Lauderdale?

Manufacturer published draft is 4.8333 ft. We keep 1 ft under-keel on the canal overlay. Victoria Park laterals are about 4.5 ft. Harbor Beach is the deep-water conversation.

Princess F55 LOA and beam versus canals?

57.75 ft LOA and 16 ft beam. Skinny isles such as Fiesta Way are limited by beam and fixed-bridge clearance.
