Pursuit S 428

center console
Outboard
open
Weekender

Overview

Draft

Air draft

Gallery

01 / 12

Sportcurrent

Dimensions

Published measurements and ranges

Hull length

Draft range

Dry weight

Deadrise

Capacities

Fresh water

Holding

Layout options

Select a published arrangement

Guest cabins

Heads

Engine options

Published packages and performance data

Powerplant

HP each

Propulsion

Performance

Speed ranges and documented profiles

Cruise

Top speed

Range

Cruise

Speed

Range

OEM Quad 450 table; 32.0 mph @ 3500 rpm; range at 90% fuel; test personnel 4; full boat test weight 32,107 lb on 2023-05-01 sheet

Dimension variants

Motors Up

Motors Down

Fort Lauderdale fit

Air draft 9 ft 2 in. 17th Street closed ≈ 55 ft. SE 3rd Avenue ≈ 16 ft. Manufacturer numbers, not a survey.

Survey watch points

Draft labeled 2'10" vs 3'9" without motors-up/down clarity

high risk · unresolved · documentation

OEM publishes Hull Draft Motors Up 2'10" and Motors Down 3'9". Some 2021 reviews list only 2'10"/34" (sometimes as Draft max), while Power & Motoryacht lists 3'9".

Canonical draft_ft uses OEM motors-down 3.75 ft as the conservative maximum, with draft_ft_min 2.83 (motors up). Do not collapse the two OEM datums into one unlabeled number.

Confirm prop/engine down draft for the delivered lower-unit configuration before shallow-water planning; treat single unlabeled draft figures as ambiguous.

Sources: pursuit-s-428-oem-brochure, pursuit-s-428-oem-performance-quad-450, boating-pursuit-s-428-2021, power-and-motoryacht-pursuit-s-428, saltwater-sportsman-pursuit-s-428-fishability

Dry weight 26,519 vs ~23,600 lb across sources

medium risk · unresolved · documentation

Current OEM Quad 450 brochure/performance sheet publish approx./average dry weight 26,519 lb, while 2021 editorial specs publish about 23,600 lb dry for Quad 425 packages.

Canonical dry_weight_lb keeps current OEM Quad 450 26,519. The 23,600 figure remains conflict evidence for earlier 425-era coverage.

Verify loaded displacement and engine package on survey; do not treat 23,600 and 26,519 as interchangeable.

Sources: pursuit-s-428-oem-brochure, pursuit-s-428-oem-performance-quad-450, boating-pursuit-s-428-2021, power-and-motoryacht-pursuit-s-428, saltwater-sportsman-pursuit-s-428-fishability

Fuel capacity 518 vs 547 US gal across sources

medium risk · unresolved · documentation

Current OEM Quad 450 brochure/performance sheet publish 518 US gal net fuel capacity, while 2021 press/tests publish 547 gal for the earlier Quad 425 package.

Canonical fuel_capacity_us_gal keeps the current OEM Quad 450 sheet value 518. Do not average with 547.

Confirm tank placard/capacity for the specific hull and whether the boat is a 425-era or 450-era build before planning range.

Sources: pursuit-s-428-oem-brochure, pursuit-s-428-oem-performance-quad-450, boating-pursuit-s-428-2021, power-and-motoryacht-pursuit-s-428, saltwater-sportsman-pursuit-s-428-fishability

Can a Pursuit S 428 clear Fort Lauderdale bridges?

Published air draft is 9.17 ft hardtop. 17th Street closed is about 55 ft. SE 3rd Avenue is about 16 ft. Manufacturer numbers, not a listing photo.

What draft does a Pursuit S 428 need in Fort Lauderdale?

Manufacturer published draft is 3.75 ft. We keep 1 ft under-keel on the canal overlay. Victoria Park laterals are about 4.5 ft. Harbor Beach is the deep-water conversation.

Pursuit S 428 LOA and beam versus canals?

43.75 ft LOA and 13 ft beam. Skinny isles such as Fiesta Way are limited by beam and fixed-bridge clearance.
