SeaVee 390Z

center console
Outboard
open

Overview

Draft

Air draft

Gallery

01 / 04

Zdiscontinued

Dimensions

Published measurements and ranges

Dry weight

Deadrise

Capacities

Fresh water

Holding

Engine options

Published packages and performance data

Powerplant

Total HP

Propulsion

Fort Lauderdale fit

Air draft 9 ft. 17th Street closed ≈ 55 ft. SE 3rd Avenue ≈ 16 ft. Manufacturer numbers, not a survey.

Survey watch points

Air draft from 2014 Boating Mag only — OEM unpublished

high risk · documented · dimensions

OEM 390Z owner’s manual and SeaVee Z inserts omit bridge clearance / air draft. Canonical air_draft_ft 9 comes from Boating Magazine’s 2014 Bridge Clearance 9'0″ strip — measure the finished hardtop/tower before fixed-bridge transit.

OEM Z-model principal dimensions omit air draft. Canonical air_draft_ft uses Boating Magazine’s Bridge Clearance: 9’0″ (2014). air_draft_tower_ft stays unpublished — brochure options include towers / upper station without a published tower-up height.

Measure hardtop (and any upper station / tower) air draft on the surveyed hull; do not rely solely on the 2014 editorial 9'0″ figure when towers or aftermarket tops are fitted.

Sources: boating-mag-seavee-390z-2014, seavee-390z-owners-manual, seavee-z-insert-2021

Fuel / water / waste — Z manual vs Z brochure

medium risk · unresolved · documentation

390Z owner’s manual Z-model fuel 563 gal, fresh water 30 gal, waste 15 gal disagree with 2021 Z insert Open figures 550 / 56 / 19 gal (LE fresh water 60 gal).

Z-model OEM documents disagree on capacities. Canonical values prefer the owner’s manual Z Model fuel 563 gal, fresh water 30 gal, and waste 15 gal, with brochure Open/LE figures retained only as conflicting evidence. Do not average capacities or invent min/max endpoints from the disagreement.

Match tank stickers / fill plates on the specific hull; do not treat brochure vs manual disagreement as a fillable configuration range.

Sources: seavee-390z-owners-manual, seavee-z-insert-2021

Hull draft — Z manual 24" vs Z brochure 26"

medium risk · unresolved · documentation

OEM 390Z owner’s manual lists hull draft 24" for 390 outboard; the 2021 SeaVee Z insert lists 390 Z Open/LE hull draft 26".

OEM Z-model sources disagree on hull draft. The 390Z owner’s manual states 24"; the 2021 Z insert states 26" for both Open and LE. Canonical draft_ft uses the brochure 26" (2.17 ft) as the conservative maximum supported draft. Do not average 24" and 26" into a fake configuration range.

Confirm the surveyed hull’s OEM sheet / options (engines up vs down, gearcase) before treating either figure as a hard canal limit.

Sources: seavee-390z-owners-manual, seavee-z-insert-2021

Max HP — manual 1600 vs brochure 1800

medium risk · unresolved · documentation

390Z owner’s manual Max. Hp. Rating is 1600 Hp; 2021 Z insert Max HP table is 1,800 while the same Open intro says up to 1,600 hp.

OEM Z sources disagree on maximum horsepower. Canonical engine_options.outboard-up-to-quad.total_hp follows the owner’s manual 1600 Hp rating. The brochure table 1,800 value and same-page 1,600 hp body text remain unresolved conflicts — do not average them.

Confirm the hull’s rated maximum horsepower from the capacity plate / OEM options sheet for that model year before comparing engine packages.

Sources: seavee-390z-owners-manual, seavee-z-insert-2021

Can a SeaVee 390Z clear Fort Lauderdale bridges?

Published air draft is 9 ft hardtop. 17th Street closed is about 55 ft. SE 3rd Avenue is about 16 ft. Manufacturer numbers, not a listing photo.

What draft does a SeaVee 390Z need in Fort Lauderdale?

Manufacturer published draft is 2.17 ft. We keep 1 ft under-keel on the canal overlay. Victoria Park laterals are about 4.5 ft. Harbor Beach is the deep-water conversation.

SeaVee 390Z LOA and beam versus canals?

39 ft LOA and 11 ft beam. Skinny isles such as Fiesta Way are limited by beam and fixed-bridge clearance.
